ED10W LoRaWAN GPS Watch
- Connectivity via LoRa
- Class type: Class C
- GNSS+WIFI (optional) positioning
- Tracking your daily activity：Heart rate, step, Body temperature and sleep monitor.
- SOS for cloud platform management
Description
ED10W is a smart wristband with GPS/ LoRa®/WI-FI functions. combined with motion sensors can achieve real-time positioning. With wearing detection, it can realize real-time collection of health data such as heart rate, body temperature, number of steps and sleep. the detected data will be transmitted back to the server platform through the LoRaWAN base station.
Application
Team management: Outdoor Safety, Lone Worker Safety.
Specification
| Parameters | Specification |
|---|---|
| Modem | ISM Band LoRa® |
| Frequency | CN470MHz, AS923MHz |
| Class Type | Class C |
| Positioning | Build in GNSS, WIFI (optional)and accelerometer |
| Display | 240*240 TFT Display |
| Rubber strap | 22mm standard size |
| Buttons | Two function buttons |
| Battery capacity | Polymer battery，400mAh， 3.8V |
| Charging | Magnetic charging cable |
| Enclosure | IP65 |
| Electronic tags | Support RFID (NFC Tag and M1 card) (for payment, public transportation, access control, etc.) (not equipped by default) |
| Health data | Heart rate, blood pressure, pedometer, sleep detection |
| Alarm | SOS alarm，Low power alarm |
| Operation temperature | 0~60℃ |
| Operation humidity | 10%～90%，Non-condensing |
| Dimensions | TYP. 48*52*14.5mm (W*L*H) |
| Weight | 50g |
