ED5201-A LoRaWAN Asset Tracker
- Communicate via LoRa， No SIM card required
- Industry-Leading Battery Life & Reliability
- Build-in GPS/GLONASS and BLE chipset, support indoor and outdoor positioning
- Rugged & waterproof
- Easy Integration
Description
ED5201-A is a LoRa based asset tracker support GPS and BLE positiong, Build in two Li-SOCl2 battery, with low power consumption, long battery life and communication range. The asset tracker’s location data will uplink to LoRaWAN gateway according to the schedule you choose.
Application
Vehicle and feet management in airports, seaports, construction site, mining, oil&gas etc industries.
Downloads
Specification
| Parameters | Specification |
|---|---|
| Frequency Band | 868~928MHz，Optional |
| Battery Specs | 38000mah Li − SOCl2 battery, Non rechargeable |
| Temperature | -45~+75°C |
| Dimensions | 185*57*53mm (Weight 360g) |
| Communication range | 9KM LoS， 3-5KM in dense environment |
| Transmit Power | +18dBm |
| Modulation | LoRa Modulation Patented by Semtech |
| Protection Requirements | IP67 |
| Antenna | External rubber duck antennna |
| Positioning accuracy | Indoor 5-8M, outdoor 20M |
